- General Information
- Manufacturer
- Cooler Master Co., Ltd
- Manufacturer Website Address
- http://www.coolermaster.com
- Brand Name
- Cooler Master
- Product Series
- Elite Series
- Marketing Information
Back-Connected Motherboard Support
Supports back-connected motherboard design, freeing up space at the front of the case and providing 33-35mm of space behind the motherboard tray for easier cable management.
Optimized Airflow
Equipped with three 120mm ARGB fans, it offers stable cooling performance while adding stunning lighting effects to your build.
USB Type-C Upgrade
USB Type C port built into the I/O panel allows multi-purpose, streamlined data transmission.
Room For Updates
Supports a 410mm GPU, a 170mm CPU cooler, and ample space for future hardware upgrades.
Versatile Thermal Options
Supports up to seven 120mm fans and either a top-mounted 360mm radiator or a front-mounted 420mm radiator, offering hyper-effective CPU thermal performance.
Removable HDD Cage
The HDD cage is completely removable, providing better access during assembly and system upgrades.
- Product Type
- Computer Case
- Technical Information
- Motherboard Supported
- ITX
- Micro ATX
- ATX
- EATX
- Number of Fans Supported
- 7
- Fan Supported Details
Fan Support - Front(Filtered) 140 mm x 3 / 120 mm x 3
Fan Support - Top(Filtered) 140 mm x 2 / 120 mm x 3
Fan Support - Rear1x 120mm
- Number of Fans Installed
- 3
- Fan Size Supported
- 120 mm
- 140 mm
- Installed Fan Size
- 120 mm
- Installed Fan Size Details
- 3 × 120mm
- Features
- Cable Management
- Dust Filter
- Window Panel
- Yes
- Window Panel Location
- Left Side
- Bays
- Number of Internal 3.5" Bays
- 2
- Number of Internal 2.5" Bays
- 2
- Number of Total Expansion Bays
- 4
- I/O Expansions
- Total Number of Expansion Slots
- 7
- Interfaces/Ports
- Total Number of USB Ports
- 2
- USB Port Details
- 1 x USB 3.2 Gen 1 Type-A
- 1 x USB 3.2 Gen 1 Type-C
- Front USB
- Yes
- Total Number of Audio In Ports
- 1
- Front Audio In
- Yes
- Total Number of Audio Out Ports
- 1
- Front Audio Out
- Yes
- Physical Characteristics
- Color Family
- White
- Product Color
- White
- Product Material
- Steel
- Tempered Glass
- Mesh
- Cooler Type
- Fan Cooler
- Form Factor
- Mid-tower
- Maximum CPU Cooler Height
- 170 mm
- Maximum PSU Length
- 210 mm
- Maximum GPU Length
- 410 mm
- Height
- 481 mm
- Width
- 230 mm
- Depth
- 474 mm
- Weight (Approximate)
- 8.89 kg
