- General Information
- Manufacturer
- Hewlett Packard Enterprise
- Manufacturer Website Address
- https://www.hpe.com/au/
- Brand Name
- HPE
- Product Line
- ProLiant Compute
- Product Series
- DL320 Gen12
- Product Type
- Server
- Warranty
- Additional Warranty Information
3/3/3 Server Warranty includes three years of parts, three years of labor, and three years of on-site support coverage.
- Processor
- Number of Processors Supported
- 1
- Number of Processors Installed
- 1
- Processor Manufacturer
- Intel
- Processor Type
- Xeon 6
- Processor Model
- 6505P
- Processor Core
- Dodeca-core (12 Core)
- Processor Speed
- 2.20 GHz
- Cache
- 48 MB
- Chipset
- Chipset Manufacturer
- Intel
- Memory
- Standard Memory
- 32 GB
- Maximum Memory Supported
- 4 TB
- Memory Technology
- DDR5 SDRAM
- Error Checking
- ECC
- Total Number of Memory Slots
- 16
- Number of Occupied Memory Slots
- 1
- Signal Processing
- Registered (Buffered)
- Storage
- Number of Solid State Drives
- 2
- Total Solid State Drive Capacity
- 1.88 TB
- Solid State Drive Interface
- Serial ATA/600
- Solid State Drive Configuration
- 2 x 960GB
- Controllers
- Controller Type
- Serial ATA/600
- 12Gb/s SAS
- NVMe
- Controller Model
- MR408i-o Gen11
- RAID Supported
- Yes
- RAID Levels
- 0, 1, 5, 6, 10, 50, 60
- I/O Expansions
- Number of Total Expansion Bays
- 8
- Number of Internal 2.5" Bays
- 8
- Number of SFF Bays
- 8
- Hot Swappable Bays
- Yes
- Total Number of Expansion Slots
- 2
- Display & Graphics
- Graphics Memory Capacity
- 16 MB
- Network & Communication
- Ethernet Technology
- Gigabit Ethernet
- Interfaces/Ports
- Total Number of USB Ports
- 4
- Network (RJ-45)
- Yes
- Number of Network (RJ-45) Ports
- 4
- VGA
- Yes
- Number of VGA Ports
- 1
- Remote Management
- Yes
- Power Description
- Input Voltage
- 120 V AC
- 230 V AC
- Number of Power Supplies Supported
- 2
- Number of Power Supplies Installed
- 2
- Maximum Power Supply Wattage
- 1 kW
- Redundant Power Supply
- Yes
- Hot Swappable Power Supply
- Yes
- Power Source
- Power Supply
- Physical Characteristics
- Form Factor
- Rack
- Rack Height
- 1U
- Height
- 42.8 mm
- Width
- 434.6 mm
- Depth
- 607.5 mm
- Weight (Approximate)
- 17.25 kg
- Miscellaneous
- Package Contents
- ProLiant Compute DL320 Gen12 Server
- Easy Install Rail 1 Kit
- Security Features
- UEFI Secure Boot and Secure Start support
- Secure Enclave - Silicon Root of Trust 2.0
- Quantum resistant (PQC) readiness for signing firmware - CNSA 2.0
- FIPS 140-3 validation (Planned)
- Common Criteria certification (Planned)
- USGv6 ready (Section 508 - VPAT)
- Secure Standard Mode - default security mode (equivalent of higher security mode in Gen 11)
- Configurable for PCI DSS compliance
- Advanced Encryption Standard (AES) on browser
- Support for Commercial National Security Algorithms (CNSA)
- Tamper-free updates - components digitally signed and verified
- Secure Recovery - recover critical firmware to known good state on detection of compromised firmware
- Ability to rollback firmware
- Secure erase of NAND
- Front bezel key-lock feature - standard, available in both Tower and Rack models
- Padlock slot, standard
- Kensington Lock slot, standard
- Chassis Intrusion detection option
- TPM (Trusted Platform Module)
- Energy Star
- Yes
