- General Information
- Manufacturer
- TP-LINK Technologies Co., Ltd
- Manufacturer Website Address
- http://www.tp-link.com.au
- Brand Name
- VIGI
- Marketing Information
Human & Vehicle Classification
Intelligently distinguishes humans and vehicles from other objects, so you receive more accurate event notifications
VIGI Surveillance Solution
The VIGI professional surveillance system by TP-Link is dedicated to protecting the business that you've worked hard to build-whenever, wherever.
Outstanding functions, reliable quality guarantees, and simplified installation work together to ensure your business stays safe and sound.
- Product Type
- Network Camera
- Technical Information
- Recording Formats
- 4K
- HD Recording
- Yes
- Night Vision
- Yes
- Night Vision Distance
- 30 m
- Night Vision Type
- Infrared/Color
- Number of IR LEDs
- 2
- Infrared (IR) Cut-off Filter
- Yes
- Wide Dynamic Range Detail
- 120 dB
- Display & Graphics
- Image Sensor Type
- CMOS
- Image Sensor Size
- 1/2.7"
- Colour Supported
- Colour
- Field of View
- Horizontal FOV: 91.5°, Vertical FOV: 46.1°, Diagonal FOV: 109.6°
- Effective Camera Resolution
- 8 Megapixel
- Video
- Video Formats
- H.265+
- H.265
- H.264+
- H.264
- H.265 (MP)
- H.264 HP
- Maximum Video Resolution
- 3840 x 2160
- Maximum Frame Rate
- 25 fps
- Audio
- Audio Support
- Yes
- Lens
- Lens Type
- Fixed
- Maximum Focal Length
- 4 mm
- Lens Included
- Yes
- Lens Mount Type
- M12-mount
- Maximum Aperture
- f/1.6
- Exposure
- Shortest Shutter Speed
- 1/10000 Second
- Longest Shutter Speed
- 1/3 Second
- Network & Communication
- Connectivity Technology
- Wired
- Ethernet Technology
- Fast Ethernet
- Protocols
- TCP/IP
- UDP
- ICMP
- HTTP
- HTTPS
- DHCP
- DNS
- RTSP
- NTP
- UPnP
- SSL/TLS
- FTP
- SFTP
- IPv4
- IPv6
- ARP
- ONVIF
- Remote Management
- Yes
- Storage
- Storage Type
- Memory Card
- Interfaces/Ports
- Network (RJ-45)
- Yes
- Power Description
- Maximum Power Consumption
- 11.50 W
- Input Voltage
- 12 V DC
- Power Source Type
- DC
- PoE
- Physical Characteristics
- Mount Type
- Ceiling Mount
- Wall Mount
- Pole Mount
- Form Factor
- Bullet
- Durability
- Water Proof
- Weather Proof
- Product Material
- Metal
- Height
- 74 mm
- Width
- 184 mm
- Length
- 74 mm
- Diameter
- 74 mm
- Weight (Approximate)
- 520 g
- Environmental Conditions
- Minimum Operating Temperature
- -30°C
- Maximum Operating Temperature
- 60°C
- Minimum Storage Temperature
- -40°C
- Maximum Storage Temperature
- 60°C
- Maximum Operating Humidity (Non-condensing)
- 95%
- Maximum Storage Humidity (Non-condensing)
- 95%
- Miscellaneous
- Features
- Password Protection
- HTTPS Encryption
- Mirror
- Privacy Masking
- 3D Digital Noise Reduction
- Wide Dynamic Range
- Back Light Compensation (BLC)
- Cross Line Detection
- Human Detection
- Motion Detection
- Tamper Detection
- Region of Interest
- Built-in Microphone
- Built-in Speaker
- SD Card Local Storage
- Indoor/Outdoor
- Outdoor
- Ingress Protection Rating
- IP67
